TIG Equipments - Origo, Caddy and Aristo Series


ESAB TIG 401iw
ESAB Logo

TIG 401iw - Heavy Duty TIG Welding Power Source With Cooling Unit

Heavy Duty & User Friendly

TIG 401iw is an IGBT based inverter controlled power source with in-built high efficiency cooling unit designed for heavy duty applications of high frequency (HF) TIG welding & MMA welding. The user-friendly interfaces for torch and water cooling unit connections minimise the risk of leakages.

  • Digital Ammeter and Voltmeter.
  • Individual knobs for parameter setting.
  • In-built trolley with cooling unit and cylinder mount.
  • High efficiency Cooling Unit with flow guard.

Visit esabindia.com for more information.

Welding Process Icons
TIG 401iw Machine

Industry

  • General Fabrication
  • Pipe Welding
  • Ship Building
Welder Image

Specification

Mains Supply, V / Ph, Hz415 ± 10% / 3, 50/60
Rated Input Power, kVA18.7
Permitted Load at 60% Duty Cycle, A400
Permitted Load at 100% Duty Cycle, A310
Power Factor0.93
Efficiency at Maximum Current, %85
Current Range: TIG / MMA, A20–400 / 25–350
Open Circuit Voltage (OCV), V65
Dimensions (L x W x H), mm977 x 420 x 913
Weight, Kg65
Enclosure ClassIP21S

Cooling Unit

Input Voltage, V / Ph415 / 1
Input Power, W350
Capacity, L6.5
Drainage Capacity, L/min20
Maximum Pressure, Bar2.4

Ordering Information

DescriptionPart Number
TIG 401iw4640210410
IAR 52B (2 Gauge) Argon4330196320
TIG Professional Gloves2001005003
Savage A40 9-13 Yellow0700000481
Welding Apron (Large)2001007001
Welding Sleeve2001007002
Welding Leg Guard2001007003

Note: TIG 401iw is delivered with 3m mains cable, In-built Cooling Unit with Cylinder Mounted Trolley, 3m Earth Cable and Earth Clamp.

Click here to view manual of TIG Equipments - Origo, Caddy and Aristo Series in PDF format (470 KB)
