TIG 310i
Heavy Duty Industrial TIG Equipment
Rugged &Reliable
TIG 310i is a digitally controlled AC/DC TIG inverter welding power source with HF start and consistent, stable arc in both DC and AC modes. Its Integrated cooling unit ensure trouble free welding for heavy duty applications.
 |
 |
|
 |
 |
SAILENT FEATURES
- Widemains voltage tolerance– 415V +/- 15%
- HF/Scratch TIG selection
- Pulsing in both AC / DC operation
- ACBalanceadjustment
- Integrated cooling unit with Flow sensor
- In-built protections against overheating, under voltage and coolant flow failure
- Process industry
- Pipe and tube manufacturing
- General fabrication
- Shipbuilding and Offshore
- Automotive
- Repair and Maintenance
Application Areas
| Specification/ Technical Data | |
| class="table_row3">Power Source | TIG 310i |
| Welding process suitability | TIGDC, TIG AC, MMA |
| Mains supply, V/Ph, Hz | 415 ±15% / 3, 50/60 |
| Input power, KVA (max) | 13.6 |
| Output current range DC/AC/MMA | 10/20/20 –315/315/250 |
| Output current at 100%duty cycle | Tig –186A , MMA-148A |
| Slope up Time | 0-10 Sec |
| Slope down Time | 0-25 Sec |
| Gas Pre Flow Time | 0-10 Sec |
| Gas Post Flow Time | 0.2-20 Sec |
| Pulse Frequency | DC0.1-250 Hz, AC 0.1-20 Hz |
| Cooling Unit Volume | 6.5 l |
| CoolantPressure | 35psi |
| Coolant Flow sensor Protection | Yes |
| Overheating / Under Voltage Protection | yes |
| Cooling unit input supply | 415Vfrom Power Source. |
| Enclosure | IP21S |
| Insulation class | f |
| Dimensions, lxwxh, | 1080x 500 x 900 mm |
| Weight | 60kg |
| Ordering Information | |
| Description | Part Number |
| TIG310i | 4640230300 |
| TBiSR-P 26, 4M | 405P843F64 |
| TXH 251W, 4M | 0700300561 |
| TIG HAND GLOVES | 405P843F74 |
| TBiSR-P 36, 8M | 2001005010 |
| Welder’s Jacket | 2001007006 |
Click here to view manual of TIG 310i AC_DC in PDF format
(640 KB)
